Locomotives – Croatia 2022.

Shunting locomotives are designed primarily for shunting wagons at train stations and marshalling yards. They were formerly used as industrial locomotives and for train haulage on open lines, which is something very rare these days. At present, there are two series of shunting locomotives running on Croatian railroads, namely diesel-hydraulic locomotives series HŽ 2132 and diesel-electric locomotives series HŽ 2041.

Diesel-hydraulic locomotive series HŽ 2132/JŽ 732
The HŽ 2132/JŽ 732 locomotives were built between 1969 and 1970 at the “Đuro Đaković” Factory in Slavonski Brod under license of the Austrian company Jenbacher Werke. The first locomotive was put into service on 15 October 1969. A total of 132 locomotives were built, 72 for the present-day Hrvatske željeznice railway company, 25 for the Slovenian railway company and 25 used for the purposes of industrial maneuvering. In 1977, another 10 locomotives of this series were commissioned by Hrvatske željeznice. Originally, these locomotives were equipped with a 441 kW (600 HP) Jenbach JW600 two-stroke diesel engine, a Voith L26St/v hydraulic transmission, a Voith N6 600/2 intermediate transmission, and a Voith A 30SK axle transmission.

Following 1975, the locomotives underwent gradual refurbishment and, since 1988, modernization. The modernization works included the installation of new Pielstick 6PA4V 184 VG and Jenbach JW 240 D four-stroke diesel engines, the installation of a new Voith L 3r4 turbo reversing hydraulic power transmission, as well as an upgrade of the cooling capacity of the front water cooler. As the result of the refurbishments and modernization, the sub-series of the locomotives 2132-000 (retaining the original power), 2132-100, 2132-200 and 2132-300 were created. Refurbishment and modernization works were carried out by TŽV “Gredelj“, the rolling stock factory from Zagreb, and other partners.

The installed power of the locomotive is 441 kW (600 HP), the tractive force is 397 kW (540 HP), the maximum speed reaches 30–60 km/h, the wheel diameter is 950 mm, the weight is 44 tons, the axle load is 14 tons and the length over the buffers is 10,500 mm.

Diesel-hydraulic locomotive series HŽ 2133/JŽ 734
Diesel-hydraulic locomotives of series HŽ 2133 were built between 1955 and 1964 at the German factory Maschinen Fabrik-Kiel AG. The locomotives are equipped with three drive shafts connected by rodes and hydraulic transmission, a built-in four-stroke diesel V engine with two cylinders connected to a common crankshaft. The transmission is located at the tail of the locomotive in the bogie and consists of hydraulic torque converter, driving mode converter and timetable converter.

In 1986, the Jugoslavenske željeznice railway company purchased a total of 15 used locomotives from the Deutsche Bahn, which were deployed at the railway administrations in Zagreb, Belgrade and Skopje. This included 10 German series V 260 locomotives (in the JŽ substructure series 0, in the HŽ substructure series 000) and five series V 261 locomotives (in the JŽ substructure series 1, in the HŽ substructure series 100). The series differed in the performance of the diesel engine. Due to their German origin, the locomotives obtained the popular name Švabice (Swabian girls).

Date of Issue – 06 Oct 2022 Face Value -10.00 HRK each Print run-30,000 Se-Tenant Pair
